Manufacturing: PSG’s Blackmer sliding vane pumps

Vane pumps are 24% more efficient than gear pumps, estimated $552 - $1,771 energy cost savings.

PSG

Blackmer

Blackmer pumps

Problem

Poor pump design, pump selection, and improper system operation can result in higher energy costs.

Solution

By eliminating the need to increase the pump speed over time, sliding vane pumps save additional energy when compared to gear pumps. Sliding vane pumps are inherent energy savers by virtue of their design.

Annually, sliding vane pumps can account for $552 - $1,771 in energy cost savings when compared to internal gear pumps.

Download a PDF of the complete case study for more information.


Annual Energy Cost Savings: Sliding Vane vs. Internal Gear Pumps

Liquid viscosity Pump L/Min (GPM) bar (PSI) BHP WHP (Water) Efficiency
(motor rated at 88%)
kW input Annual power cost Annual savings w/sliding vane pumps
Pump USD EUR RMB USD EUR RMB
Pump Sized for Stated Flow
Thin 1 cSt Sliding vane 1174 (310) 5.71 (75) 20.1 13.6 68% 17.0 $3,828 €2,708.31 ¥24,643.52 $552 €390.54 ¥3,553.61
Internal gear 23.0 59% 19.5 $4,380 €3,098.85 ¥28,197.13
Viscous 5,250 cSt Sliding vane 682 (180) 5.71 (75) 12.2 7.9 65% 10.3 $2,323 €1,643.52 ¥14,954.78 $1,485 €1,050.64 ¥39,559.98
Internal gear 20.0 39% 17.0 $3,809 €2,694.87 ¥24,521.20
Pump Sized for Wear Factor Allowance
Thin 1 cSt Sliding vane 1174 (310) 5.71 (75) 20.1 13.6 68% 17.0 $3,828 €2,708.31 ¥24,521.52 $1,333 €943.10 ¥8,581.45
Internal gear 27.1 50% 23.0 $5,161 €3,651.41 ¥33,224.97
Viscous 5,250 cSt Sliding vane 682 (180) 5.71 (75) 12.2 7.9 65% 10.3 $2,323 €1,643.52 ¥14,954.78 $1,771 €1,252.98 ¥311,401.17
Internal gear 21.5 37% 18.2 $4,094 €26,355.94 ¥26,355.94
